Flanged Inside Corner – Architectural Trims – Millwork

Architectural Trims – Millwork – Flanged Inside Corner

With the help of these aluminum Flanged Inside Corner trims, achieving a polished and professional look for inside wall corners is a breeze. Specifically designed for inside corners, these Flanged Inside Corner trims offer a clean and refined aesthetic and feature a .19″ return key to protect panel edges from damage and wear and tear. Millwork channel inside corners with return keys are mainly used to provide a perfectly straight inside corner edge for a truly professional finish.

Eagle Aluminum’s Millwork EMT-12 Flanged Inside Corners are made from 6063-T5 aluminum which has a smooth surface and is ideally structured for anodized finishing, making it the perfect material for aluminum trim extrusions. Available in both 1.00″ and .75″ profile depths, these millwork channel inside corners with return keys are stocked in 10′ (120″) lengths in Clear Satin Anodized and Mill Finish. A variety of color anodized and powder coat finishes are available upon request to enhance the beauty of your wall panel material and craft your distinct vision. When panels are installed with Z clip ZCP-375 (.25″ stand-off), these millwork flanged inside corners accommodate .50″ or .75″ panels.

Summary of Key Features:

• This Millwork Flanged Inside Corner Architectural Trim is stocked in 10′ lengths (120 inches)
• Stocked in Clear Satin Anodized (EA) and Mill Finish (MF)
• Available in 2 Profile depths:
  • 1.00″ Profile depth, EMT-12100 (Dimension A = 1.00″)
  • .75″ Profile depth, EMT-12075 (Dimension A = .75″)
• Alloy/Temper: 6063-T5 Aluminum
• Specialty finishes available upon request
• Z Clip recommended for panel hanging ZCP-375
• Commonly used in the architectural, construction, millwork, store fixture and display industries
• Comparable to MWCISC100 and MWCISC75
